shunt capacitors

advantages:
improved power factor
reduced transmission losses
increased transmission capacity
improved voltage control
improved power quality

shunt capacitor (internal fuse)

shunt capactitor(internal fuse)
no	type number	kv rated voltage	kvar rated capacity	μf rated capacitance	kg weight	w mm	h1 mm	h mm
1	bam 11/√3 -300-1w	11/√3	300	23.7	52	180	525	200
2	bam 11/√3 -334-1w	11/√3	334	26.4	56	180	575	200
3	bam 11/√3 -400-1w	11/√3	400	31.6	64	180	650	200
4	bam 11/√3 -500-1w	11/√3	500	39.5	76	180	825	200
5	bam 11/√3 -600-1w	11/√3	600	47.4	87	180	950	300
6	bam 11/√3 -700-1w	11/√3	700	55.3	97	200	975	300
7	bam 11/2-334-1w	5.5	334	35.2	56	180	575	200
8	bam 11/2-500-1w	5.5	500	52.6	76	180	800	200
9	bam 11/2-600-1w	5.5	600	63.2	87	180	950	200
10	bam 11/2-700-1w	5.5	700	73.7	97	200	975	200
11	bam 11/2-800-1w	5.5	800	84.2	108	200	1075	200
12	bam 11-500-1w	11	500	13.2	76	180	800	400
13	bam 11-600-1w	11	600	17.5	87	180	950	400

shunt capacitor (external fuse)

shunt capactitor(external fuse)
no	type	kv rated voltage	kvar rated capacity	μf rated capacitance	kg weight	w mm	h1 mm	h mm
1	bam 11/√3 -100-1w	11/√3	100	7.9	29	140	300	100
2	bam 11/√3 -200-1w	11/√3	200	15.8	40	140	475	100
3	bam 11/√3 -300-1w	11/√3	300	23.7	52	180	525	200
4	bam 11/√3 -334-1w	11/√3	334	26.4	56	180	575	200
5	bam 11/√3 -400-1w	11/√3	400	31.6	64	180	650	200
6	bam 11/√3 -500-1w	11/√3	500	39.5	76	180	825	300
10	bam 11/2-100-1w	5.5	100	10.5	29	140	300	100
11	bam 11/2-200-1w	5.5	200	21.1	40	140	475	100
12	bam 11/2-300-1w	5.5	300	31.6	52	180	525	200
13	bam 11/2-334-1w	5.5	334	35.2	56	180	575	200
14	bam 11/2-400-1w	5.5	400	42.1	64	180	650	200
15	bam 11/2-500-1w	5.5	500	52.6	76	180	800	300
18	bam 11/2-800-1w	5.5	800	84.2	108	200	1075	400
19	bam 11-100-1w	11	100	2.6	29	140	300	100
20	bam 11-200-1w	11	200	5.3	40	140	475	100
21	bam 11-300-1w	11	300	7.9	52	180	525	200
22	bam 11-334-1w	11	334	8.8	55	180	575	200
23	bam 11-400-1w	11	400	10.5	64	180	650	200
24	bam 11-500-1w	11	500	13.2	75	180	800	300
27	bam 11-800-1w	11	800	21.1	106	200	1075	400
28	bam 24-300-1w	24	300	1.7	53	180	550	53
29	bam 24-334-1w	24	334	1.8	57	180	600	57
30	bam 24-400-1w	24	400	2.2	65	180	675	65
31	bam 24-500-1w	24	500	2.8	77	180	825	77

we recommend capacitor units with rated voltage 12kv or lower to use single or double bushing.
we recommend capacitor units with rated voltage over 12kv to use single bushing.
capacitor units with rated capacitance over 800kvar, please contact us.
for other special products, please contact us.
